NAB-1000 AIS
AIS

Frequency Range: 156.025~162.025MHz (full channels) Default Channels: CH2087, CH2088 Band Width: 25kHz Output Power: 2W Communication Mode: CSTDMA Sensitivity: Better than -10…
询价/Quote
描述DESCRIPTION 规格参数SPECIFICATION

          -      Meet the latest IMO regulation and ITU standards, such as IEC 62287-1, ITU-R.M 1371-5.
  -      Compatible with AIS AtoN, AIS SART and MOB.
  -      High stability and easy maintenance.
  -      Built-in isolated PSU with wide range input.

          -      Design for non-Solas vessels with CSTDMA technology.

          -      Can communicate with other AIS transponders, including shipborne Class A AIS, Class B AIS, AtoN AIS

                 station, AIS base stations.

          -      CCS type approval.

          -      VR type approval.

 Frequency Range:  156.025162.025MHz (full channels)
 Default Channels  CH2087, CH2088
 Band Width:  25kHz
 Output Power  2W
 Communication Mode  CSTDMA
 Sensitivity  Better than -109 dBm
 Data Ports  one RS-232, one RS-422
 Data Format/Baud Rate:  NMEA-0183, 38400bps
 Ant Connectors  50Ω, TNC (GPS Ant), BNC(VHF Ant)
 Power Source:     24V DC(1238V)
 Size:    81(H) x 174(W) x 160(D) mm
 Weight:    1.4 kg  (transponder)
 IP Grade:  IP22 (Transponder), IP66 (Antenna)
