ItemsParametersAnode voltage (Peak)8 kVAnode current (Peak)8 AHeater voltage6.3 V (@ Preheat)Heater current1.25 ARF output interfaceWaveguide : WR284Power supply interfaceLead wireC…
3040 ~ 3060 MHz (Fixed)
Output power (Peak)
25 kW
Duty cycle / Pulse duration
0.001 / 1.00 μsec
Other features
RoHS compliant
Items Parameters
Anode voltage (Peak) 8 kV
Anode current (Peak) 8 A
Heater voltage 6.3 V (@ Preheat)
Heater current 1.25 A
RF output interface Waveguide : WR284
Power supply interface Lead wire
Cooling Air / Forced air
Weight 2.3 kg
