| Type |
Frequency (MHz) |
Peak Power Output (kW typ.) |
Pulse Duration (μsec) |
Duty Cycle |
Peak Anode Voltage (kV) |
Peak Anode Current (A) |
Heater Voltage (V) |
Heater Current (A) |
Class |
Weight (kg) |
| M118 | 8500 ~ 9600 | 40 | 1 | 0.001 | 14 | 14 | 6.3 | 1 | MWAPS | 2.3 |
|---|---|---|---|---|---|---|---|---|---|---|
| M1926 | 9330 ~ 9470 | 70 | 0.9 | 0.0009 | 15 | 14 | 12.6 | 2.2 | MWAPS | 3.5 |
| M1976 | 9000 ~ 9600 | 220 | 2 | 0.001 | 21.5 | 27.5 | 13.75 | 3.1 | MWAPS | 13 |
| M1976B | 9300 ~ 9400 | 300 | 2 | 0.001 | 30 | 30 | 13.75 | 2.9 | MWLPS | 13 |
